- 产品描述
-
Rated power (kw/rpm): 147kw
Cooling method: Water cooling
Cylinder diameter x stroke (mm): 110 x 127
Exhaust volume (L): 7.2
Basic performance
Bucket capacity (m ³): 2.5-3.5
Rated load capacity (ton): 6 tons or more
Operating weight of the whole machine (kg): 18338
Unloading height - Unloading angle of 45 ° (mm): 2922
Oil capacity
Fuel tank (L): 314
Hydraulic oil tank (L): 110
Coolant (L): 42
Dimensions
Wheelbase (mm): 3350
Minimum ground clearance (mm): 412
Bucket width (mm): 2927
Hydraulic system
At rated flow speed (l/min): 270
Working device action time
Lifting (s): 6.2
Uninstall (s): 1.3
Lower the empty bucket (s): 2.5
Three items and (s): 10
Transmission
Driving speed 1st gear (km/h): 6.9/7.6
Driving speed 2nd gear (km/h): 12.7/13.9
Driving speed 3rd gear (km/h): 22.3/24.5
Driving speed in 4th gear (km/h): 37/40
Technical Parameter
Overturning load (kg): 10915kg
